NiO and Co-Doped NiO Multifunctional Nanomaterials: Biogenic Fabrication for Enhanced Photocatalytic Activity

Shah Sadia Rahman  Joya; Md. Estabrak Ahammod Sakib; Md. Lael Hasan; Hridoy Roy; Md. Farhan Muskan

doi:10.38032/scse.2026.4.293

Authors

Shah Sadia Rahman Joya Department of Ceramic & Metallurgical Engineering, Rajshahi University of Engineering & Technology, Rajshahi-6204
Md. Estabrak Ahammod Sakib Department of Ceramic & Metallurgical Engineering, Rajshahi University of Engineering & Technology, Rajshahi-6204
Md. Lael Hasan Department of Ceramic & Metallurgical Engineering, Rajshahi University of Engineering & Technology, Rajshahi-6204
Hridoy Roy Department of Ceramic & Metallurgical Engineering, Rajshahi University of Engineering & Technology, Rajshahi-6204
Md. Farhan Muskan Department of Ceramic & Metallurgical Engineering, Rajshahi University of Engineering & Technology, Rajshahi-6204

DOI:

https://doi.org/10.38032/scse.2026.4.293

Keywords:

Biogenic Synthesis, Rosella Fruit, Photocatalytic Activity, Dye degradation

Abstract

Biogenically synthesized NiO and Co-doped NiO nanoparticles were fabricated using Rosella fruit extract as a natural reducing and capping agent. Structural analysis confirmed a cubic lattice with successful Co incorporation, resulting in a reduction of crystallite size from 10.73 nm to 8.93 nm and an increase in dislocation density. SEM imaging revealed agglomerated cubic morphologies, while EDS certified the elemental purity of Ni, O, and Co. UV-Visible spectroscopy showed a red-shifted absorption edge and band gap narrowing from 3.15 eV to 2.72 eV, favoring electron excitation. FTIR spectra confirmed the presence of metal-oxygen bonding and functional groups associated with the extract. Photocatalytic testing demonstrated the enhanced performance of Co-NiO, with 95.58% degradation of methylene blue, correlating with structural refinement and optical band tailoring. These findings demonstrate the effectiveness of Co substitution in modulating the microstructure and optoelectronic properties of NiO nanoparticles for advanced photocatalytic applications.

Downloads

PDF

Downloads

Download data is not yet available.

References

[1] A. Fakhri, S. Behrouz, M. Asif, I. Tyagi, S. Agarwal, and V. K. Gupta, “Synthesis, structural and morphological characteristics of NiO nanoparticles Co-doped with boron and nitrogen,” J. Mol. Liq., vol. 213, pp. 326–331, Jan. 2016, doi: 10.1016/J.MOLLIQ.2015.09.004. DOI: https://doi.org/10.1016/j.molliq.2015.09.004

[2] K. Inbarajan and S. Sowmya, “Effectual application of green synthesized Co-doped NiO and Ce:Co-doped NiO nanomaterials in devising photo-cathode for dye-sensitized solar cells,” Ionics (Kiel)., vol. 30, no. 10, pp. 6719–6728, Oct. 2024, doi: 10.1007/S11581-024-05709-9/TABLES/4. DOI: https://doi.org/10.1007/s11581-024-05709-9

[3] H. Liu, G. Yan, F. Liu, Y. Zhong, and B. Feng, “Structural, electrochemical and optical properties of NiOxHy thin films prepared by electrochemical deposition,” J. Alloys Compd., vol. 481, no. 1–2, pp. 385–389, Jul. 2009, doi: 10.1016/J.JALLCOM.2009.03.015. DOI: https://doi.org/10.1016/j.jallcom.2009.03.015

[4] B. G. Rao, D. Mukherjee, and B. M. Reddy, “Novel approaches for preparation of nanoparticles,” Nanostructures Nov. Ther. Synth. Charact. Appl., pp. 1–36, Jan. 2017, doi: 10.1016/B978-0-323-46142-9.00001-3. DOI: https://doi.org/10.1016/B978-0-323-46142-9.00001-3

[5] S. Thakur, R. Kumar, N. K. Dhiman, and A. Kumar, “Enhanced photocatalytic performance of Ce-doped NiO nanoparticles synthesized by coprecipitation method,” Hybrid Adv., vol. 6, p. 100225, Aug. 2024, doi: 10.1016/J.HYBADV.2024.100225. DOI: https://doi.org/10.1016/j.hybadv.2024.100225

[6] S. Agrawal, A. Parveen, and A. Azam, “Microwave assisted synthesis of Co doped NiO nanoparticles and its fluorescence properties,” J. Lumin., vol. 184, pp. 250–255, Apr. 2017, doi: 10.1016/J.JLUMIN.2016.12.035. DOI: https://doi.org/10.1016/j.jlumin.2016.12.035

[7] M. Jothibas, K. Bharanidharan, E. Paulson, M. Elayaraja, B. A. Kumar, and A. Muthuvel, “Effect of co-dopant proportion on the structural, optical and magnetic properties of pristine NiO nanoparticles synthesized by Sol–gel method,” J. Mater. Sci. Mater. Electron., vol. 33, no. 2, pp. 907–919, Jan. 2022, doi: 10.1007/S10854-021-07361-9/METRICS. DOI: https://doi.org/10.1007/s10854-021-07361-9

[8] P. A. Sheena, H. Hitha, A. Sreedevi, and T. Varghese, “Microstructural characterization and modified spectral response of cobalt doped NiO nanoparticles,” Mater. Chem. Phys., vol. 229, pp. 412–420, May 2019, doi: 10.1016/J.MATCHEMPHYS.2019.03.033. DOI: https://doi.org/10.1016/j.matchemphys.2019.03.033

[9] M. El-Kemary, N. Nagy, and I. El-Mehasseb, “Nickel oxide nanoparticles: Synthesis and spectral studies of interactions with glucose,” Mater. Sci. Semicond. Process., vol. 16, no. 6, pp. 1747–1752, Dec. 2013, doi: 10.1016/J.MSSP.2013.05.018. DOI: https://doi.org/10.1016/j.mssp.2013.05.018

[10] T. Tamesgen, M. A. Ameya, G. Sisay, L. Yuanqi, Z. Kai, and T. T. Beyene, “Harnessing the power of S/N-doped NiO nanoparticles through bandgap tuning to achieve enhanced photocatalytic and antibacterial performances,” Sci. Rep., vol. 15, no. 1, Dec. 2025, doi: 10.1038/S41598-025-13151-8. DOI: https://doi.org/10.1038/s41598-025-13151-8

[11] D. Adler and J. Feinleib, “Electrical and Optical Properties of Narrow-Band Materials,” Phys. Rev. B, vol. 2, no. 8, p. 3112, Oct. 1970, doi: 10.1103/PhysRevB.2.3112. DOI: https://doi.org/10.1103/PhysRevB.2.3112

[12] A. Diha, S. Benramache, and B. Benhaoua, “Transparent nanostructured Co doped NiO thin films deposited by sol‒gel technique,” Optik (Stuttg)., vol. 172, pp. 832–839, Nov. 2018, doi: 10.1016/J.IJLEO.2018.07.062. DOI: https://doi.org/10.1016/j.ijleo.2018.07.062

[13] B. Sahin, F. Bayansal, M. Yüksel, and H. A. Çetinkara, “Influence of annealing to the properties of un-doped and Co-doped CdO films,” Mater. Sci. Semicond. Process., vol. 18, no. 1, pp. 135–140, Feb. 2014, doi: 10.1016/J.MSSP.2013.11.014. DOI: https://doi.org/10.1016/j.mssp.2013.11.014

[14] P. M. Ponnusamy, S. Agilan, N. Muthukumarasamy, M. Raja, and D. Velauthapillai, “Studies on cobalt doped NiO nanoparticles prepared by simple chemical method,” J. Mater. Sci. Mater. Electron., vol. 27, no. 1, pp. 399–406, Jan. 2016, doi: 10.1007/S10854-015-3767-8/METRICS. DOI: https://doi.org/10.1007/s10854-015-3767-8

[15] M. E. A. Sakib, M. L. Hasan, H. Roy, M. M. Hasan, and M. M. Ali, “Colocasia esculenta leaf extracted cobalt oxide nanoparticles: A comprehensive investigation of the microstructural, morphological, antibacterial, and photocatalytic activity,” Next Nanotechnol., vol. 8, p. 100215, Jan. 2025, doi: 10.1016/J.NXNANO.2025.100215. DOI: https://doi.org/10.1016/j.nxnano.2025.100215

[16] N. Chongwilaikasem, P. Sithisarn, P. Rojsanga, and P. Sithisarn, “Green extraction and partial purification of roselle (Hibiscus sabdariffa L.) extracts with high amounts of phytochemicals and in vitro antioxidant and antibacterial effects,” J. Food Sci., vol. 89, no. 12, p. 8819, Dec. 2024, doi: 10.1111/1750-3841.17418. DOI: https://doi.org/10.1111/1750-3841.17418

[17] R. Uthrakumar, M. Venkatachalapathy, S. K, N. Rajkamal, C. M, and K. K, “A Study of the Application, Synthesis, and Removal Mechanisms of Co Doped Nio Nanoparticles for Wastewater Treatment,” 2023, doi: 10.2139/SSRN.4455431. DOI: https://doi.org/10.2139/ssrn.4455431

[18] G. Bharathy and P. Raji, “Pseudocapacitance of Co doped NiO nanoparticles and its room temperature ferromagnetic behavior,” Phys. B Condens. Matter, vol. 530, pp. 75–81, Feb. 2018, doi: 10.1016/J.PHYSB.2017.10.106. DOI: https://doi.org/10.1016/j.physb.2017.10.106

[19] K. Varunkumar, R. Hussain, G. Hegde, and A. S. Ethiraj, “Effect of calcination temperature on Cu doped NiO nanoparticles prepared via wet-chemical method: Structural, optical and morphological studies,” Mater. Sci. Semicond. Process., vol. 66, pp. 149–156, Aug. 2017, doi: 10.1016/J.MSSP.2017.04.009. DOI: https://doi.org/10.1016/j.mssp.2017.04.009

[20] M. S. Wu and W. H. Hsu, “Nickel nanoparticles embedded in partially graphitic porous carbon fabricated by direct carbonization of nickel-organic framework for high-performance supercapacitors,” J. Power Sources, vol. 274, pp. 1055–1062, Jan. 2015, doi: 10.1016/J.JPOWSOUR.2014.10.133. DOI: https://doi.org/10.1016/j.jpowsour.2014.10.133

[21] M. Alagiri, S. Ponnusamy, and C. Muthamizhchelvan, “Synthesis and characterization of NiO nanoparticles by sol-gel method,” J. Mater. Sci. Mater. Electron., vol. 23, no. 3, pp. 728–732, Mar. 2012, doi: 10.1007/S10854-011-0479-6. DOI: https://doi.org/10.1007/s10854-011-0479-6

[22] K. Jayanthi, S. Chawla, K. N. Sood, M. Chhibara, and S. Singh, “Dopant induced morphology changes in ZnO nanocrystals,” Appl. Surf. Sci., vol. 255, no. 11, pp. 5869–5875, Mar. 2009, doi: 10.1016/J.APSUSC.2009.01.032. DOI: https://doi.org/10.1016/j.apsusc.2009.01.032

[23] K. Vallalperuman, M. Parthibavarman, S. Sathishkumar, M. Durairaj, and K. Thavamani, “Synthesis and characterization of Co and Mn doped NiO nanoparticles,” Korean J. Chem. Eng., vol. 31, no. 4, pp. 639–643, Feb. 2014, doi: 10.1007/S11814-013-0286-2/METRICS. DOI: https://doi.org/10.1007/s11814-013-0286-2

[24] V. Raja, S. K. Puvaneswaran, and K. Swaminathan, “Unique and hierarchically structured novel Co3O4/NiO nanosponges with superior photocatalytic activity against organic contaminants,” Front. Mater. Sci., vol. 11, no. 4, pp. 375–384, Dec. 2017, doi: 10.1007/S11706-017-0399-3/METRICS. DOI: https://doi.org/10.1007/s11706-017-0399-3

[25] R. S. Kate, S. C. Bulakhe, and R. J. Deokate, “Co doping effect on structural and optical properties of nickel oxide (NiO) thin films via spray pyrolysis,” Opt. Quantum Electron., vol. 51, no. 10, pp. 1–19, Oct. 2019, doi: 10.1007/S11082-019-2026-2/METRICS. DOI: https://doi.org/10.1007/s11082-019-2026-2

[26] S. Yousaf et al., “Tuning the structural, optical and electrical properties of NiO nanoparticles prepared by wet chemical route,” Ceram. Int., vol. 46, no. 3, pp. 3750–3758, Feb. 2020, doi: 10.1016/J.CERAMINT.2019.10.097. DOI: https://doi.org/10.1016/j.ceramint.2019.10.097

[27] M. A. M. Khan, R. Siwach, S. Kumar, J. Ahmed, and M. Ahamed, “Hydrothermal preparation of Zn-doped In2O3 nanostructure and its microstructural, optical, magnetic, photocatalytic and dielectric behaviour,” J. Alloys Compd., vol. 846, Dec. 2020, doi: 10.1016/J.JALLCOM.2020.156479. DOI: https://doi.org/10.1016/j.jallcom.2020.156479

[28] T. V. Thi, A. K. Rai, J. Gim, and J. Kim, “High performance of Co-doped NiO nanoparticle anode material for rechargeable lithium ion batteries,” J. Power Sources, vol. 292, pp. 23–30, May 2015, doi: 10.1016/J.JPOWSOUR.2015.05.029. DOI: https://doi.org/10.1016/j.jpowsour.2015.05.029

[29] S. Panimalar et al., “Studies of MnO2/g-C3N4 hetrostructure efficient of visible light photocatalyst for pollutants degradation by sol-gel technique,” Surfaces and Interfaces, vol. 20, p. 100512, Sep. 2020, doi: 10.1016/J.SURFIN.2020.100512. DOI: https://doi.org/10.1016/j.surfin.2020.100512

[30] X. Xin et al., “Effect of synthesis conditions on the performance of weakly agglomerated nanocrystalline NiO,” J. Alloys Compd., vol. 427, no. 1–2, pp. 251–255, Jan. 2007, doi: 10.1016/J.JALLCOM.2006.02.064. DOI: https://doi.org/10.1016/j.jallcom.2006.02.064

[31] M. A. Shafique et al., “Bandgap engineering of NiO, and enhanced photocatalytic performance by Ca doping,” Optik (Stuttg)., vol. 267, Oct. 2022, doi: 10.1016/J.IJLEO.2022.169634. DOI: https://doi.org/10.1016/j.ijleo.2022.169634

[32] J. Pavlović, N. N. Tušar, and N. Rajić, “The Synthesis and Photocatalytic Efficacy of Distinct Nano-Oxides in the Breakdown of Organic Contaminants,” Catal. 2024, Vol. 14, Page 771, vol. 14, no. 11, p. 771, Oct. 2024, doi: 10.3390/CATAL14110771. DOI: https://doi.org/10.3390/catal14110771
